Description
ORACLE Lighting 2021-2024 Ford Bronco Off Road LASER + LED Fog Light Kit for Steel BumperIf the Bronco is not equipped with the optional Aux Switches ORACLE offers a harness (Part# 2088-504) for easy wiring installation. Not only are these lights bright and project for an impressive distance, but the styling is also very innovative. The skeletonized mount holds the individual futuristic LED and Laser Emitters with full leveling capabilities built into each individual emitter for functional aiming for the light. The Fog Light and the two individual Laser Auxiliary Light Modules each come in their own separate die-cast aluminum housings (three in total) which are individually adjustable when connected to the skeletonized mount. Each individual housing features a high-performance polycarbonate lens and heat-dissipating fins. The overall appearance is not only functional but the tactical blacked-out design is further enhanced by the laser-etched bezels around each projector lens. Disclaimer, Buyer acknowledges that the laser function of this light is not intended for road use and will only be used in an appropriate manner off-road. Buyer is solely responsible for any claims arising out of Buyer’s non-compliance with this provision.
- Input Voltage: 12VDC
Information:
LASER/LED Fog – White
Application Summary:
| Year | Make/Model |
|---|---|
| 2021-2024 | Ford Bronco |
| Attributes | |
| Add-on | N/A, N/A |
| Amp Draw | 3.6A / LED Laser, 3.6A / LED Laser |
| Bulb Quantity | 6 |
| Bulb Technology | LED |
| Bulb Type | LED |
| Bulbs Included | Yes |
| Color | 6000K |
| Country of Origin (Primary) | CN |
| Department of Transportation Approved | Yes |
| Fog Light Case Finish | Black Powder Coat |
| Fog Light Lens Color | Clear |
| Harmonized Tariff Code (Schedule B) | 8539214040 |
| Hazardous Material Code | N |
| Housing Color | Black |
| Housing Material | Die-cast aluminum, Die-cast aluminum |
| Housing Shape | Square |
| Ingress Protection | IP67, IP67 |
| Input Voltage | 12VDC, 12VDC |
| Laser Projection Distance | 3250 Ft, 3250 Ft |
| LED Projection Distance | 980 Ft, 980 Ft |
| Length | 332 |
| Lens Material | Polycarbonate, Polycarbonate, Polycarbonate |
| Life Cycle Status Code | Available to Order |
| Mount | Powder Coated Carbon Steel, Powder Coated Carbon Steel |
| Mounting Hardware Included | No |
| NAFTA Preference Criterion Code | B |
| Raw Lumens | 7000 Total Raw Lumens, 7000 Total Raw Lumens |
| SDR Required Flag | N |
| Street Legal | Yes |
| Switch Included | No |
| Terminal Quantity | 4 |
| Terminal Type | Pin |
| Total Power | 100W (30W LED+ 20W Laser), 100W (30W LED+ 20W Laser) |
| Voltage | 12 |
| Warranty Time | 1 |
| Wattage | 100 |
| Wiring Harness Included | Yes |
| GTIN | 00810030398691 |
