Description
BD190705-10PK Complete Bundle Kit
Complete kit bundle containing all necessary components for your project. Professional-grade components designed for reliable performance and long-lasting durability.
This Kit Includes:
• 10x Bulldog Square Trailer Jack, Side Mount, 8,000 lbs. Support Capacity, Top Wind, Weld-On, 10 in. Travel (BD190705)
What’s Included:
Bulldog Square Trailer Jack, Side Mount, 8,000 lbs. Support Capacity, Top Wind, Weld-On, 10 in. Travel Part #BD190705Qty: 10
Brand: BULLDOG
Square Trailer Jack, Side Mount, 8,000 lbs. Support Capacity, Topwind, Weld-On, 10 Inch Travel
Description
BULLDOG 8,000 lbs. support capacity square jack serves the agricultural, industrial, construction, horse/livestock trailer, and utility/cargo trailer markets. The compact design of these jacks makes them ideal for tight-fitting applications where 3″ and 4″ square tube jacks are too big!
- Use the painted outer tube as the final finish or primer
- Zinc-plated inner tube and drop leg
- 4.7″ Outer / inner tube overlap – results in optimal side load performance
- 5/8″ screw stem – provides insurance against screw stem twisting off
- Patented screw nut stop – prevents screw and/or nut damage when jack is fully extended
- Topwind models – bushing in top cap, eagle claw grip
- Sidewind models – 1/4″ cross pin connects gear train to screw stem – guards against shearing jack pin
- Sidewind models – 1:1.33 gear ratio
Specifications
| BRAND: | BULLDOG |
| PART NUMBER: | 190705 |
| WARRANTY: | LIMITED 5 YEAR WARRANTY |
| WEIGHT: | 18.5 LBS |
| CAPACITY: | 8,000 LBS. |
| TRAVEL: | 10 IN. |
| RETRACTED: | 11.41 IN. |
| EXTENDED: | 21.41 IN. |
| CLEARANCE: | 4.25 IN. |
| MODEL NUMBER: | TWS 190 FL-B TSMQ W/P&C |
| HANDLE STYLE: | TOPWIND |
| SPEEDY LIFT: | NO |
| MATERIAL: | STEEL |
| HANDLE BUSHING INCLUDED: | YES |
| ATTACHED WHEELS: | NO |
| COLOR: | GRAY |
| FINISH: | GRAY PAINT |
| GEARS INCLUDED: | YES |
| ROLL PINS INCLUDED: | YES |
| WASHERS INCLUDED: | YES |
Product Video
Bundle Benefits & Features:
- Complete Kit Solution – All components included for your project needs
- Quality Assurance – All genuine parts with manufacturer warranty
- Cost Savings – Bundle pricing saves money versus individual purchases
- Professional Installation Ready – Matching specifications eliminate fitment issues
- Time Efficient – One-stop solution reduces ordering complexity
- Compatibility Guaranteed – All components tested for compatibility
Product Specifications:
- Kit Type: Complete Bundle Kit
- Components: 1 Professional Grade Parts
- Application: Industrial & Professional Use
- Warranty: Manufacturer Warranty Included
- Compatibility: Designed for Optimal Performance
Keywords: BD190705-10PK bundle kit, complete kit, professional components, industrial kit, BD190705, BULLDOG
