Description
For use with Concept or Xtreme LED bulbs to add load to any vehicle lighting system. Add on 15W of load to the headlight system to offset the error caused by the CANBUS system. A wire wound resistor potted inside of a aluminum heat sink with the vehicle specific connector.
- Eliminates any light failure diagnostic of CANbus system
- Load equivalent wattage 15W (12) ohm resistors
- Easy to install with factory connector
- 2 Year Warranty
| Attributes | |
| Country of Origin (Primary) | CN |
| Current Draw@12VDC | 1.2 |
| Hazardous Material Code | N |
| Housing Material | Cast Aluminum |
| IP Rating | IP65, IP67 |
| Life Cycle Status Code | Available to Order |
| Maximum Amperage | 1.5 |
| NAFTA Preference Criterion Code | B |
| Operating Temperature | -40 to 185 |
| Resistance | 12 |
| SDR Required Flag | N |
| Universal Or Specific Fit | Specific Fit |
| Voltage | 9-16V, 9~16 |
| Warranty Time | 1 |
| Wattage | 15, 21 |
| GTIN | 00793888980884 |
