Description
- Push Capacity: 110 Ton(s)
- Stroke: 6″
- Lowered Height: 13.51″
- Raised Height: 19.51″
- Plunger Diameter: 5.11″
- Pull Capacity: 63 Ton(s)
- Cylinder Affective Area (Advance/Retract): 22.144″²/12.562″²
- Oil Capacity (Advance/Retract): 132.8″³/75.3″³
- Outside Diameter: 8.38″
- Cylinder Bore Diameter: 6.5″
- Base to Coupler Port: 1.41″
- Saddle Distance Above Cylinder: 0.5″
- Hollow Hole design allows for both push and pull applications
- Chrome plated piston rod eliminates corrosion and rust
- Dual wiper seals keep out contamination and debris
- Double acting for fast retraction
- Collar threads for easy fixturing
- 3/8″ NPTF female coupler and dust cap
